NodeJS Server explained

In this article I'll try to explain how a NodeJS server works. The basics that every NodeJS developer should know to efficiently build and debug any kind of node applications.

Nowadays software developers are used to work with different frameworks for building server-side applications like Express, Koa or Nest. These frameworks are really good and help us to build large, scalable applications, but they also abstract a lot of interesting things behind them. Using frameworks creates a magic effect, but we don't believe in magic, do we?

Lets start from scratch, and create a simple web server using node docs. Snippet below creates a server, which respond Hello world string when you access localhost:3000.

import { createServer } from 'node:http'
const hostname = '127.0.0.1'
const port = 3000
const server = createServer((req, res) => {
  res.statusCode = 200
  res.setHeader('Content-Type', 'text/plain')
  res.end('Hello World')
})
server.listen(port, hostname, () => {
  console.log(`Server running at http://${hostname}:${port}/`)
})

What does the createServer function do? It creates an instance of the http.Server class, which inherits from the net.Server class. This, in turn, extends the EventEmitter class. As you may know, an EventEmitter can emit various events. If you're unfamiliar with this concept, check out the article: [[Node.js EventEmitter explained]]. However, at this point, we’re only interested in the request event, which is emitted whenever an HTTP request is received. This event provides both the request and response objects.

The code above is just a wrapper for:

const server = new http.Server()

server.on('request', (req, res) => {
  res.end('Hello!')
})

The http.Server instance gives you access to methods and events like:

  • server.listen(...)
  • server.close()
  • server.on('request', ...)
  • server.on('connection', ...)
  • server.timeout
  • server.maxHeadersCount
  • And more…

Because it inherits from EventEmitter, so you can listen to low-level events.

Now that we understand what happens when the server receives an HTTP request, let’s take a closer look at the request and resposen objects.

Both request and response are stream objects—request is a Readable stream, while response is Writable. This allows us to leverage the full power of NodeJS streams when working with them. To learn more about Streams check [[NodeJS Streams explained]] article.

Basic HTTP Server with Routing

We’re already able to handle incoming requests, but now we need to figure out how to differentiate and process them individually. The request object provides all the necessary metadata for this, such as:

  • req.method - HTTP method like GET, POST, etc.
  • req.url - The full URL (path + query string)
  • req.headers - An object with all headers
  • req.httpVersion - HTTP version string
  • req.socket - The underlying TCP socket

To implement basic routing, we can extract the path using the req.url and access additional information through the req.headers property.

const path = new URL(req.url, `http://${req.headers.host}`).pathname

Then, we can route the requests based on the extracted path.

switch (path) {
  case '/': {
    res.setHeader('Content-Type', 'text/html')
    res.end('<h1>Hello World</h1>')
    break
  }
  case '/upload': {
    return uploadHandler(req, res)
  }
  case '/posts': {
    return postsHandler(req, res)
  }
}

Inside each handler we can handle each request based on the method using req.method property.

async function postsHandler(req, res) {
  switch (req.method) {
    case 'POST':
      res.statusCode = 200
      res.setHeader('Content-Type', 'application/json')
      res.end(JSON.stringify({ status: 'ok' }))
      break
    case 'GET':
      res.statusCode = 200
      res.setHeader('Content-Type', 'application/json')
      res.end(JSON.stringify({ status: 'ok' }))
      break
  }
}

How to get path params?

To get path params (dynamic values embedded directly in the URL path that are used to identify a specific resource) form request object we need to manually parse URL created from req.url property.

  const pathname = const path = new URL(req.url, `http://${req.headers.host}`).pathname // e.g. /users/42/posts/7

  const segments = pathname.split('/').filter(Boolean);

  if (segments[0] === 'users' && segments[2] === 'posts') {
    const userId = segments[1];
    const postId = segments[3];

    res.writeHead(200, { 'Content-Type': 'application/json' });
    res.end(JSON.stringify({ userId, postId }));
  } else {
    res.writeHead(404);
    res.end('Not Found');
  }

How to get query params?

Use the searchParams property of the URL interface to retrieve query parameters (key-value pairs that are appended to the end of a URL to filter, sort, search, paginate, or otherwise modify the request). This property is read-only and returns an URLSearchParams object. This object allows us to decode query parameters contained in the URL.

/** /posts?ids=1,2,3 */
const parsedUrl = new URL(req.url, `http://${req.headers.host}`)
const searchParams = parsedUrl.searchParams
const ids = searchParams.get('ids') // '1,2,3'

Here we get a query params string, which then can be parsed and validated.

How to retrieve a JSON data from a request Stream?

Streams transmit data in small chunks. To obtain the complete data, we need to collect and concatenate all of these chunks.

There are several ways to achieve this:

  1. Listen data event (default event of Readable Stream)
let body = []

req.on('data', (chunk) => {
  body.push(chunk)
})

Here we listen data event and collect binary data chunks in array.

req.on('end', () => {
    const fullBody = Buffer.concat(body);
    const bodyStr = new TextDecoder().decode(fullBody)
    const bodyJSON = JSON.parse(bodyStr)


    res.statusCode = 200;
    res.setHeader('Content-Type', 'application/json');
    res.end(JSON.stringify({ status: 'ok' }))
})

The end event is emitted once all chunks have been received. To retrieve the full request body, we can concatenate the chunks and decode them into a string. After that, we can parse the string as JSON if needed.

Note: If the expected body is a string (e.g., JSON payload), you can directly concatenate the chunks as strings.

let body = '';

req.on('data', chunk => {
	body += chunk; // == body = body + chunk.toString();
	const decodedChunk = new TextDecoder().decode(chunk)
	...
});
  1. Use async iterator for await...of
const chunks = []
for await (const chunk of req) {
  chunks.push(chunk)
}
const fullBody = Buffer.concat(chunks)

This syntax is cleaner and more readable.

  1. Use stream/consumers.text() (Node.js 18+)
import { text } from 'stream/consumers'

const body = await text(req)
console.log('Body:', body)

Also available: buffer(), json(), and arrayBuffer().

Using popular framework Express it can be done:

app.use(express.text())
app.post('/', (req, res) => {
  console.log(req.body) // already parsed!
})

How to retrieve a binary data from a request Stream

There is no difference between retrieving string or binary data, as all data chunks from the request are always raw binary data (Buffer objects). The final result depends solely on how we choose to decode (interpret) that raw data.

  • Is it text? Decode it with Buffer.toString() or TextDecoder.
  • Is it an image? Save or process it as binary.
  • Is it JSON? Decode as UTF-8 and then JSON.parse().
  • Is it a file upload? Parse it using multipart/form-data logic.
async function uploadHandler(req, res) {
  switch (req.method) {
    case 'POST':
      const chunks = []
      for await (const chunk of req) {
        chunks.push(chunk)
      }

      const fullBody = Buffer.concat(chunks)

      try {
        fs.promises.writeFile('./uploads/image.jpg', fullBody)
      } catch (e) {
        throw new Error(`Error writing file: ${e.message}`)
      }
      res.statusCode = 200
      res.setHeader('Content-Type', 'application/json')
      res.end(JSON.stringify({ status: 'ok' }))
      break
    case 'GET':
      res.statusCode = 200
      res.setHeader('Content-Type', 'application/json')
      const respData = Readable.from([JSON.stringify({ status: 'ok' })])
      respData.pipe(res)
      break
  }
}

We can also handle this more efficiently by using streams.

const fileStream = fs.createWriteStream('./uploads/image.jpg')
req.pipe(fileStream)

Congratulations! You now have the knowledge and understanding needed to build any type of NodeJS server.

While using pure Node.js is a great learning experience, it’s not the most convenient approach for building large or complex projects. Still, having a solid grasp of the native NodeJS APIs is essential for every developer.
